6146

The 6146 is a 20 watt beam pentode with a maximum frequency of 60 MHz and usable to 175 MHz. The 6146A is a mobile rated version and the 6883 is the same tube with a 12.6 volt heater. The 6146W is a ruggedized version and the 8032 is a 13.5 volt "dark heater" version. The 6159 is a 26.5 volt version.

Length = 3.51" Diameter = 1.65"
Max voltage = 750
Max current = 135 ma
Fil voltage = 6.3
Fil current = 1.25 amps         GOTO INDEX
