6159

The 6159 is a 20 watt beam pentode with a maximum frequency of 60 MHz and usable to 175 MHz. The 6159 is a 26.5 volt version of the 6146.

Length = 3.51" Diameter = 1.65"
Max voltage = 750
Max current = 135 ma
Fil voltage = 26.5
Fil current = 300 ma         GOTO INDEX
