WE356B

The WE356B is a 60 watt triode with a mu of 50 and a maximum frequency of 100 MHz for full ratings. The tube was used at reduced ratings to 250 MHz.

Length = 4.50" Diameter = 2.25"
Max voltage = 600
Max current = 100 ma
Fil voltage = 5
Fil current = 5 amps         GOTO INDEX
