V-70-D

The V-70-D is a 85 watt general purpose triode. Maximum ratings to 30 MHz and similar to a T-55. Made by United.

Length = 6.87" Diameter = 1.87"
Max voltage = 1750 VDC
Max current = 200 ma
Fil voltage = 7.5 volts
Fil current = 3.25 amps         GOTO INDEX
