HY51Z

The HY51Z is a 65 watt triode with a mu of 85 and full ratings to 60 MHz. Designed by Hytron for zero bias operation.

Length = 6.50" Diameter = 2.25"
Max voltage = 1000
Max current = 175 ma
Fil voltage = 7.5
Fil current = 3.50 amps         GOTO INDEX
