8020

The 8020 is a half wave rectifier designed for high voltage and low current.

Length = 8.00" Diameter = 2.31"
Max voltage = 40000 PIV
Max current = 750 ma peak
Fil voltage = 5
Fil current = 6 amps         GOTO INDEX
