4CS250R

The 4CS250R is a conduction cooled tetrode with a maximum frequency for full power of 500 MHz. Designed for high shock and vibration applications by Eimac.

Length = 2.46" Diameter = 1.76"
Max voltage = 2000
Max current = .25 amp
Fil voltage = 6
Fil current = 2.6 amps         GOTO INDEX
